KT-5MU

Specs

Configuration: 2 DUT per chassis

Operation Modes: Manual loading / unloading. Parallel testing

Control Software: TigerClaw software installed on external Control PC with Windows 10 Professional

Number of Test Sockets: 2x 288-pin ZIF test sockets per chassis ( Each ‘Test Site’ corresponds to one DIMM test socket)

Memory Type Supported: DDR5 SDRAM 8/16 Gb density, x8/16 width

DIMM Standards Supported: DDR5 ECC and non-ECC Un-buffered DIMM
DIMM capacity 32GB max.
ECC 1R x8 / 1R x16; Non-ECC 1R x8 / 2R x8 / 1R x16

Test Frequency (Std): Clock 2000 / 2200 / 2400 / 2600 / 2800 MHz
Optional feature per MHz fine adjustment

OC Support: Over-clock memory frequency up to 4000MHz (DDR8000)
*Actual OC capability depends on DIMM performance and VDD/VDDQ settingsI/O InterfaceDDR5 CK/CA/DQ/DQS/DM POD 1.1V
DDR5 RESETn CMOS 1.1V
SPD I2C CMOS 3.3V, open-drain
PMIC PWR_GOOD POD 1.1V

Temperature Control Chamber: Optional heat chamber with integrated test plan flow control
Heat chamber temperature 85C max, +/-3C overall accuracy
Refer to Heat Chamber specifications for details
